Gecko Aqua-Flo 02093001-2010 Circ-Master HP Spa Pump 1/15HP 230V

Circ-Master HP pump, designed exclusively for spas, takes 24-hour filtration to a new level, delivering the highest GPM of any recirculation pump on the spa industry. Circ-Master pumps are powerful, efficient, high density filtration and quiet.

• Carbon-graphite self-lubricating seal designed for continuous duty operation
• 48 Frame, continuous duty construction with front and rear, permanently lubricated ball bearings for extended motor life
• Quick release compression fittings allow for easy installation or maintenance
• Ideal for 24/7 circ pump applications
• Flow rate up to 40 GPM
• Compact Design
• Includes Unions
• 1.5″ intake and discharge
• UL approval E62386
• Sealed bearing

Includes:

• 2x white 2″ union nuts with 1.5″ slip tail pieces and O-rings
• Three wing nut drain plugs
• Standard wet end position: 12 o’clock CMHP, Centered CMCP

Replaces: _02093001-2010 , 02093001-2010 , 02093007-2 , 301637 , 5127-003 , 5200-259 , 6000-907 , K55MYGRD8367 , K55MYRLT-2224 , PRC1168,02093001-2010,1-00-0204,02093695-2,02410512-2,AF020930012010,02093001-2,02093001-2510,02093002-2,02093002-2510,02093003-2010,02093003-2510,02093004-2,02093004-2510,02093006-2,02093006-2010,02093007-2,02093007-2000,02093007-2500,02093007-3500,02093400-2000,02093400-2010,02093400-2310,02093400-2510,02093448-2010,02093466-2000,02093492-2000,02093492-2010,02093634-2,02093634-2010,02093638,02093638-2,02093638-2010,02093639-2,02093639-2000,02093639-2010,02093639-2300,02093656-2,02093658-2,02093678-2,02093697-2,02093759-2,02093760-2,02403004-2,02403466-2,02403649-2,02403695-2,02405000-2500,02407002-2,02407512-2500,02407670-2510,02408492-2,02408492-2510,02410002-2,02410388-2,024110512-2,104440,6000-907,CMHP550112,K55MYGRD-8367,14154,6500-907,34-402-1140,02418000-2510,02093492-2000,02093492-2010,02093634-2010,02093634-2510,02093638-2010,02093639-2000,02093639-2010,02093639-2300,02093639-2500,02093639-2510,02093639-3010
02093639-3510,02093640-2000,02093645-3510,02093646-2510,02093646-3510,02093648-2010,02093649-2000,02093651-2020,02093658-2010,02093658-2510,02093658-2520,02093658-3510,02093670-2000,02093670-2010,02093670-2110,02093670-2300,02093670-2310,02093670-2500,02093670-2510,02093672-2000,02093674-2000,02093675-2020,02093676-2020,02093677-2020,02093677-2120,02093677-2520,02093678-2020,02093678-2500,02093678-2520,02093692-2010,02093692-2110,02093692-2510,02093693-2010,02093694-2010,02093695-2000,02093695-2100,02093695-2300,02093695-2500,02093697-2000,02093697-2010,02093697-2500,02093697-2510,02093759-2000,02093759-2100,02407003-2010,02407003-2510,02407427-2500,02407670-2510,02410002-2010,02410002-2310,02410002-3510,02410389-2510,02410427-2500,02410512-2500,02410512-3500,02410672-2510,02093016-2510,02093638-2510,02093021-2510,02093760-2100,02093017-2510,02093013-2510,02093014-2510,02093018-2510,02093012-2510,02093012-2010,02093020-2510,02093019-2510,02093015-2510,02407005-2510,02418000-2010,02093022-2510,02418003-2510,02418003-2010,02093006-2510,02093672-2010,02405000-2500,02407000-2010,02407436-2500,02407512-2500,02408492-2510,02410001-2510,02410007-2510,02410008-2510,02410011-2510,02410012-2510,02410388-2010,02410388-2510,02410436-2500,02410648-2030,02410648-2530,02410791-2000,02410991-2010,02410991-2310,02410991-2510,02475369-2010,02418001-2010

Accessory Pump Type	Circulation
Manufacturer	AquaFlo/Gecko
Pump Model	CMHP
Speed	1 Speed (1-Spd)
Motor Voltage	230v
Drain Plug Location	3,6,9 o`clock
Suction Style	Center
Suction Connection Type	Female Pipe Thread (fpt), Male Buttress Thread (mbt)
Suction Pipe Size	1-1/2"
Discharge Style	Side
Discharge Connection Type	Male Buttress Thread (mbt)
Discharge Pipe Size	1-1/2"
Horsepower	1/15hp
Motor Frame	48 Frame Thru-Bolt
Motor Amperage/Wattage	0.6A
